I want to build this Project into my Jetson Nano:
https://docs.edgeimpulse.com/experts/featured-machine-learning-projects/quality-control-jetson-nano
And this is the public Project link:
https://studio.edgeimpulse.com/public/320746/latest
I installed JetPack 4.6.1 in my Jetson nano. I followed the steps of the first link. Even I have some problems I managed to execute the command:
edge-impulse-linux-runner --model-file ./build/model.eim
Before proceeding with the point “5. Build the Application” I wanted to execute Edge Impulse’s classify.py in the examples/image folder from the linux-python-sdk directory (Once classify.py is working I want to modify it as it is done in the Original Project).
But It is not working. I can not guess where is the issue because I followed the steps and I try to execute an example. Any help is welcome.
I tried to execute this command and it says that module named ‘edge_impulse_linux’ doesn’t exist (below you have the answer when I try to install it):
jetson@jetson-desktop:~/example-standalone-inferencing-linux $ python3 topping.py ~/build/model.eim
Traceback (most recent call last):
File "topping.py", line 17, in <module>
from edge_impulse_linux.image import ImageImpulseRunner
ModuleNotFoundError: No module named 'edge_impulse_linux'
This are the versions I have instaled in my Jetson nano:
Python3 3.6.9
jetson@jetson-desktop:~$ pip3 list
appdirs (1.4.4)
apturl (0.5.2)
asn1crypto (0.24.0)
beautifulsoup4 (4.6.0)
blinker (1.4)
Brlapi (0.6.6)
certifi (2018.1.18)
chardet (3.0.4)
cryptography (2.1.4)
cupshelpers (1.0)
cycler (0.10.0)
Cython (3.0.11)
decorator (4.1.2)
defer (1.0.6)
distro-info (0.18ubuntu0.18.04.1)
ez-setup (0.9)
feedparser (5.2.1)
filesystem (0.1.4)
fs (2.4.16)
graphsurgeon (0.4.5)
html5lib (0.999999999)
httplib2 (0.9.2)
idna (2.6)
Jetson.GPIO (2.0.17)
keyring (10.6.0)
keyrings.alt (3.0)
language-selector (0.1)
launchpadlib (1.10.6)
lazr.restfulclient (0.13.5)
lazr.uri (1.0.3)
louis (3.5.0)
lxml (4.2.1)
macaroonbakery (1.1.3)
Mako (1.0.7)
MarkupSafe (1.0)
matplotlib (2.1.1)
numpy (1.13.3)
oauth (1.0.1)
oauthlib (2.0.6)
onboard (1.4.1)
pandas (0.22.0)
pip (9.0.1)
protobuf (3.0.0)
psutil (6.1.0)
PyAudio (0.2.14)
pycairo (1.16.2)
pycrypto (2.6.1)
pycups (1.9.73)
Pygments (2.2.0)
pygobject (3.26.1)
PyJWT (1.5.3)
pymacaroons (0.13.0)
PyNaCl (1.1.2)
pyparsing (2.2.0)
pyRFC3339 (1.0)
python-apt (1.6.5+ubuntu0.7)
python-dateutil (2.6.1)
python-debian (0.1.32)
pytz (2018.3)
pyxattr (0.6.0)
pyxdg (0.25)
PyYAML (3.12)
requests (2.18.4)
requests-unixsocket (0.1.5)
scipy (0.19.1)
SecretStorage (2.3.1)
setuptools (59.6.0)
simplejson (3.13.2)
six (1.16.0)
ssh-import-id (5.7)
system-service (0.3)
systemd-python (234)
tensorrt (8.2.1.8)
ubuntu-drivers-common (0.0.0)
uff (0.6.9)
unity-scope-calculator (0.1)
unity-scope-chromiumbookmarks (0.1)
unity-scope-colourlovers (0.1)
unity-scope-devhelp (0.1)
unity-scope-firefoxbookmarks (0.1)
unity-scope-manpages (0.1)
unity-scope-openclipart (0.1)
unity-scope-texdoc (0.1)
unity-scope-tomboy (0.1)
unity-scope-virtualbox (0.1)
unity-scope-yelp (0.1)
unity-scope-zotero (0.1)
urllib3 (1.22)
urwid (2.0.1)
wadllib (1.3.2)
webencodings (0.5)
wheel (0.30.0)
xkit (0.0.0)
youtube-dl (2018.3.14)
zope.interface (4.3.2)
And these are the messages:
jetson@jetson-desktop:~$ pip3 install edge_impulse_linux
Collecting edge_impulse_linux
Collecting psutil>=5.8.0 (from edge_impulse_linux)
Collecting numpy>=1.19 (from edge_impulse_linux)
Using cached https://files.pythonhosted.org/packages/51/60/3f0fe5b7675a461d96b9d6729beecd3532565743278a9c3fe6dd09697fa7/numpy-1.19.5.zip
Building wheels for collected packages: numpy
Running setup.py bdist_wheel for numpy ... error
Complete output from command /usr/bin/python3 -u -c "import setuptools, tokenize;__file__='/tmp/pip-build-w2ozj0g9/numpy/setup.py';f=getattr(tokenize, 'open', open)(__file__);code=f.read().replace('\r\n', '\n');f.close();exec(compile(code, __file__, 'exec'))" bdist_wheel -d /tmp/tmpy_577znkpip-wheel- --python-tag cp36:
Running from numpy source directory.
Cythonizing sources
performance hint: _common.pyx:275:19: Exception check after calling 'random_func' will always require the GIL to be acquired. Declare 'random_func' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:299:19: Exception check after calling 'random_func' will always require the GIL to be acquired. Declare 'random_func' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:322:50: Exception check after calling 'random_func' will always require the GIL to be acquired. Declare 'random_func' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:426:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:465:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:509:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:592:36: Exception check after calling 'f0' will always require the GIL to be acquired. Declare 'f0' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:596:36: Exception check after calling 'f1' will always require the GIL to be acquired. Declare 'f1' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:600:36: Exception check after calling 'f2' will always require the GIL to be acquired. Declare 'f2' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:604:36: Exception check after calling 'f3' will always require the GIL to be acquired. Declare 'f3' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:638:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:675:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:712:63: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:754:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:785:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:903:40: Exception check after calling 'f0' will always require the GIL to be acquired. Declare 'f0' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:907:40: Exception check after calling 'fd' will always require the GIL to be acquired. Declare 'fd' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:911:41: Exception check after calling 'fdd' will always require the GIL to be acquired. Declare 'fdd' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:916:40: Exception check after calling 'fi' will always require the GIL to be acquired. Declare 'fi' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:920:41: Exception check after calling 'fdi' will always require the GIL to be acquired. Declare 'fdi' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:924:38: Exception check after calling 'fiii' will always require the GIL to be acquired. Declare 'fiii' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:960:31: Exception check after calling 'f' will always require the GIL to be acquired. Declare 'f' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
performance hint: _common.pyx:1002:32: Exception check after calling 'f1' will always require the GIL to be acquired. Declare 'f1' as 'noexcept' if you control the definition and you're sure you don't want the function to raise exceptions.
Error compiling Cython file:
------------------------------------------------------------
...
cdef sfc64_state rng_state
def __init__(self, seed=None):
BitGenerator.__init__(self, seed)
self._bitgen.state = <void *>&self.rng_state
self._bitgen.next_uint64 = &sfc64_uint64
^
------------------------------------------------------------
_sfc64.pyx:90:35: Cannot assign type 'uint64_t (*)(void *) except? -1 nogil' to 'uint64_t (*)(void *) noexcept nogil'. Exception values are incompatible. Suggest adding 'noexcept' to the type of the value being assigned.
Processing numpy/random/_bounded_integers.pxd.in
Processing numpy/random/_common.pyx
Processing numpy/random/mtrand.pyx
Processing numpy/random/_sfc64.pyx
Traceback (most recent call last):
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 235, in <module>
main()
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 231, in main
find_process_files(root_dir)
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 222, in find_process_files
process(root_dir, fromfile, tofile, function, hash_db)
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 188, in process
processor_function(fromfile, tofile)
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 78, in process_pyx
[sys.executable, '-m', 'cython'] + flags + ["-o", tofile, fromfile])
File "/usr/lib/python3.6/subprocess.py", line 311, in check_call
raise CalledProcessError(retcode, cmd)
subprocess.CalledProcessError: Command '['/usr/bin/python3', '-m', 'cython', '-3', '--fast-fail', '-o', '_sfc64.c', '_sfc64.pyx']' returned non-zero exit status 1.
Traceback (most recent call last):
File "<string>", line 1, in <module>
File "/tmp/pip-build-w2ozj0g9/numpy/setup.py", line 508, in <module>
setup_package()
File "/tmp/pip-build-w2ozj0g9/numpy/setup.py", line 488, in setup_package
generate_cython()
File "/tmp/pip-build-w2ozj0g9/numpy/setup.py", line 285, in generate_cython
raise RuntimeError("Running cythonize failed!")
RuntimeError: Running cythonize failed!
----------------------------------------
Failed building wheel for numpy
Running setup.py clean for numpy
Complete output from command /usr/bin/python3 -u -c "import setuptools, tokenize;__file__='/tmp/pip-build-w2ozj0g9/numpy/setup.py';f=getattr(tokenize, 'open', open)(__file__);code=f.read().replace('\r\n', '\n');f.close();exec(compile(code, __file__, 'exec'))" clean --all:
Running from numpy source directory.
`setup.py clean` is not supported, use one of the following instead:
- `git clean -xdf` (cleans all files)
- `git clean -Xdf` (cleans all versioned files, doesn't touch
files that aren't checked into the git repo)
Add `--force` to your command to use it anyway if you must (unsupported).
----------------------------------------
Failed cleaning build dir for numpy
Failed to build numpy
Installing collected packages: psutil, numpy, edge-impulse-linux
Running setup.py install for numpy ... error
Complete output from command /usr/bin/python3 -u -c "import setuptools, tokenize;__file__='/tmp/pip-build-w2ozj0g9/numpy/setup.py';f=getattr(tokenize, 'open', open)(__file__);code=f.read().replace('\r\n', '\n');f.close();exec(compile(code, __file__, 'exec'))" install --record /tmp/pip-_c36g8sq-record/install-record.txt --single-version-externally-managed --compile --user --prefix=:
Running from numpy source directory.
Note: if you need reliable uninstall behavior, then install
with pip instead of using `setup.py install`:
- `pip install .` (from a git repo or downloaded source
release)
- `pip install numpy` (last NumPy release on PyPi)
Cythonizing sources
Error compiling Cython file:
------------------------------------------------------------
...
cdef sfc64_state rng_state
def __init__(self, seed=None):
BitGenerator.__init__(self, seed)
self._bitgen.state = <void *>&self.rng_state
self._bitgen.next_uint64 = &sfc64_uint64
^
------------------------------------------------------------
_sfc64.pyx:90:35: Cannot assign type 'uint64_t (*)(void *) except? -1 nogil' to 'uint64_t (*)(void *) noexcept nogil'. Exception values are incompatible. Suggest adding 'noexcept' to the type of the value being assigned.
numpy/random/_bounded_integers.pxd.in has not changed
numpy/random/_common.pyx has not changed
numpy/random/mtrand.pyx has not changed
Processing numpy/random/_sfc64.pyx
Traceback (most recent call last):
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 235, in <module>
main()
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 231, in main
find_process_files(root_dir)
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 222, in find_process_files
process(root_dir, fromfile, tofile, function, hash_db)
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 188, in process
processor_function(fromfile, tofile)
File "/tmp/pip-build-w2ozj0g9/numpy/tools/cythonize.py", line 78, in process_pyx
[sys.executable, '-m', 'cython'] + flags + ["-o", tofile, fromfile])
File "/usr/lib/python3.6/subprocess.py", line 311, in check_call
raise CalledProcessError(retcode, cmd)
subprocess.CalledProcessError: Command '['/usr/bin/python3', '-m', 'cython', '-3', '--fast-fail', '-o', '_sfc64.c', '_sfc64.pyx']' returned non-zero exit status 1.
Traceback (most recent call last):
File "<string>", line 1, in <module>
File "/tmp/pip-build-w2ozj0g9/numpy/setup.py", line 508, in <module>
setup_package()
File "/tmp/pip-build-w2ozj0g9/numpy/setup.py", line 488, in setup_package
generate_cython()
File "/tmp/pip-build-w2ozj0g9/numpy/setup.py", line 285, in generate_cython
raise RuntimeError("Running cythonize failed!")
RuntimeError: Running cythonize failed!
----------------------------------------
Command "/usr/bin/python3 -u -c "import setuptools, tokenize;__file__='/tmp/pip-build-w2ozj0g9/numpy/setup.py';f=getattr(tokenize, 'open', open)(__file__);code=f.read().replace('\r\n', '\n');f.close();exec(compile(code, __file__, 'exec'))" install --record /tmp/pip-_c36g8sq-record/install-record.txt --single-version-externally-managed --compile --user --prefix=" failed with error code 1 in /tmp/pip-build-w2ozj0g9/numpy/
